Snorkel Head Donaldson CYCLONE filter Top Spin HD (Heavy Duty) 221 mm/89mm/11,3 m³

€395,70
Article number: H002853

Snorkel Head Donaldson CYCLONE filter Top Spin HD (Heavy Duty) 221 mm/89mm/11,3 m³

Designed for Construction, Mining, Oil & Gas, Quarrying, Logging, Road and Rail Maintenance, Agriculture and anywhere your equipment encounters heavy dust and flying debris.

IMPORTANT: Mount on metal inlet tube only. Do not mount on plastic inlet tube. To be used in combination with our Aluminum snorkel on Sprinter only!

The kit contains the adapter 104-89 mm.

  • Rugged one-piece aluminum hood with recessed discharge louver sheds flying debris
  • One-piece stainless steel impeller is the only moving part. Dual bearings ensure reliable performance.
  • All the interior components are solid stainless steel to resist dirt, water, heat and abuse.
  • Stainless steel clamp with locking nut makes installation quick and secure. Clamp is included with each TopSpin HD
Height 148 MM
Housing diameter max. 221 MM
Outlet diameter inside 89 MM (104mm)
Efficiency 80 Percent (ISO 5011 / SAE J726)
Nominal airflow flow 11.3 CMM
Brut weight 2,24 KG
